MicroTCA Chassis
Our standard compliant MicroTCA chassis are designed to meet your exact requirements - from standard 19" rack-mount technology to custom designs inlcuding table-top chassis.
Depending on the use case our MicroTCA chassis solutions offer redundant or non-redundant management and data switching capabilities as well as single or n+1 power configurations.
Designed to exceed the thermal envelope as defined by the MicroTCA specification our solutions also provide exceptional cooling capabilities.
For a quick comparison, please refer to the MTCA.0 and MTCA.4 Chassis Overview.
Not shown on this page are our custom and bespoke designs we have created to fulfill special demands of our customers. Please contact us in case you are invested in this kind of service.
Products
NATIVE-mini
- Form factor: 1U, compact size
- Embedded NAT-eMCH
- Embedded 150W Power Module
- 2 single mid- or full-size AMCs or 1 double mid- or full-size AMC
NATIVE-C1
- Form factor: 1U, 19”
- 1 single full-size NAT-MCH
- 1 single full-size NAT-PM
- 1 custom size NAT-JSM
- 6 single mid-size AMCs
- 40G Backplane
NATIVE-C2
- Form factor: 2U, 19”
- 2 single full-size NAT-MCH
- 2 single full-size NAT-PM
- 1 custom size NAT-JSM
- 12 single mid-size AMCs
- 40G Backplane
NATIVE-C5
- Form factor: 5U, 0.5x 19”
- 1 double full-size NAT-MCH
- 1 double full-size NAT-PM
- 6 double mid-size + 1 double full-size AMCs
NATIVE-C8
- Form factor: 8U, 19”
- 2 double full-size NAT-MCH
- 3 double full-size NAT-PM
- 1 double compact-size JSM module
- 10 single mid-size or 12 double mid-size AMCs
NATIVE-C3-PTM
- Form factor: 3U, 19”
- 2 single full-size NAT-MCH
- 4 single full-size NAT-PM
- 2 single full-size NAT-AMC-PTM
- 12 single mid-size AMCs or 6 double mid-size AMCs
NATIVE-mini-R1
- Form factor: 1U, 19”
- Embedded NAT-eMCH
- Embedded 400W Power Module
- 2 single mid-size AMCs and 2 double mid-size AMCs
- 2 double mid-size µRTMs
NATIVE-R5
- Form factor: 5U, 0.5x 19”
- 1 double full-size NAT-MCH with NAT-MCH-RTM
- 1 double full-size NAT-PM
- 6 double mid-size + 1 double full-size AMCs
- 6 double mid-size + 1 double full-size µRTMs
NAMC-Filler
- Optimizes airflow inside the chassis
- Ensures electromagnetic shielding
- Available in various form factors
- With or without air blockers
NATIVE-R2
- Form factor: 2U, 19”
- 1 double full-size NAT-MCH with NAT-MCH-RTM
- 1 double full-size NAT-PM
- 1 single mid-size NAT-JSM
- 5 double mid-size + 1 double full-size AMCs
- 5 double mid-size µRTMs
NATIVE-R9
- Form factor: 9U, 19”
- 2 double full-size NAT-MCH with 1 NAT-MCH-RTM
- 6 double full-size NAT-PM, two of them as RPM
- 1 single full-size NAT-JSM
- 12 double mid-size AMCs
- 12 double mid-size µRTMs
